Others series

Paging machine

Automatic paging machine
Specially used for sheet products such as sheet-fed labels, plastic bags, paper bags, food bags, candy bags, snack bags, cards, paper cards, color boxes, scratch cards, etc., automatically separated and transported. It is generally used with inkjet printers, laser printers, and labeling heads to assign or label products. The speed is adjustable.
According to the characteristics of the product, there are two types of paging methods: friction type and reverse wheel type.

Click above to play the video

FEATURES

The paging features and effects of “standard paging machine” and “desktop paging machine” are the same.

The standard paging UV inkjet printing platform product uses the principle of friction to realize paging feeding, including standard “four-stage” structures such as paging feeding, corona & printing negative pressure conveying high-temperature resistant curing line, and automatic collection.

The whole machine is made of stainless steel material combined with a streamlined design style, and it is equipped with a detachable floor stand for easy packaging, saving transportation costs and space.

The unique paging structure design makes the product adaptable, easy to adjust, and easy to operate

It can be equipped with CIJ (small characters), TIJ (high resolution), and other inkjet printers, flat labeling machines, and laser coding machines to print various texts, patterns, etc.

paper, labels, cartons, ordinary plastic bags and other packaging products to complete UV printing

It adopts the discharge mode under friction, which can continue to feed without stopping

Equipped with negative pressure adsorption function, so that the product can run close to the belt without slipping or offsetting, and the surface is flat to facilitate subsequent printing or other processes to proceed smoothly

Stackable design, stacking products one by one, neatly collecting, etc.; can also be customized according to requirements.

SPECS

standard pag machine/Standard paging machine (with negative pressure adsorption + automatic collection)/Standard paging & UV printing platform

Dimensions

length*width*height=1700*640*800mm

Weight

65KG

Power supply

220VAC

Power

about 500W

Efficiency

0-300 pcs/min (take 100mm size product as reference)

Belt running speed

0-60m/min (continuously adjustable)

Product suitable size range

length*width*thickness=60-300*60-280*0.1-3mm

Speed regulation (control) method

frequency conversion or DC brushless speed regulation

Motor

variable frequency or DC brushless motor

WARRANTY

30 DAY-MONEY BACK GUARANTEE

It’s perfectly normal for you to be skeptical about investing in a new inkjet printer! That’s why FAITH PRINTER makes every effort to absorb as much risk as possible so that you are free to make the right decision. We want to make it easy for you to prove that our printing systems are quality machines backed by quality support.

As our customers, we want you to be 100% satisfied. FAITH PRINTER guarantees you a 30-day return guarantee window (from the date of receipt) to evaluate your purchase. Click here for details.

2 YEAR LIMITED WARRANTY

FAITH PRINTER warrants its products and parts against defects in materials or workmanship for two (2) years from the original date of receipt. Click here for detail
